2356FT
Carbon Steel Full Port 3-Piece Ball Valve, Threaded Ends, Fire Safe
DESIGN FEATURES
| Sizes | 1/4" - 2" | |
| Class | Figure | |
| Pressures | 2000 - 1500 WOG | 2366FT & 2366FW & 2366FTxS |
| 2000 - 1500 WOG | 2356FT & 2356FW & 2356FTxS | |
| Material | CF8M & WCB | |
| Ends | Threaded, Socketweld, and THD x SWE | |
| Trim | 316 Stainless Steel Trim; Graphite Packing & Gasket; RTFE Seats | |
| Features | Slide Latch Locking Device; Fire Safe; NACE MR0175; ISO 5211 Mounting Pad; 150 PSIG Saturated Steam Rating | |
